retail-app

An example retail application composed of a few serverless components. The application has a frontend that displays a catalog of products. The backend relies on a REST API that in turn fetches data from a DynamoDB table. The application is deployable to AWS.

Live Preview Here

Getting Started

Note: Make sure you have Node.js 8+ and npm installed on your machine

1. npm install --global serverless-components
2. Setup the environment variables
   • export AWS_ACCESS_KEY_ID=my_access_key_id
   • export AWS_SECRET_ACCESS_KEY=my_secret_access_key
3. clone this repo to bring down the example code.

$ git clone https://github.com/serverless/components.git

4. cd into this example

$ cd components/examples/retail-app

Operations

Deploy

To deploy the application and create all dependent resources automatically, simply do:

$ components deploy

On deploy, the system executes each child component in parallel based on the dependencies:

Creating Bucket: 'retail-vwlchq8e57.example.com'
Creating Bucket: 'www.retail-vwlchq8e57.example.com'
Creating Role: func-vwlchq8e57-czpijqla-execution-role
Creating Role: func-vwlchq8e57-llfmq73p-execution-role
Creating Role: func-vwlchq8e57-8p74j047-execution-role
Created table: 'products-vwlchq8e57'
Seeding 3 items into table products-vwlchq8e57.
Creating Lambda: func-vwlchq8e57-8p74j047
Creating Lambda: func-vwlchq8e57-llfmq73p
Creating Lambda: func-vwlchq8e57-czpijqla
Item inserted to table: 'products-vwlchq8e57'
...
Setting policy for bucket: 'retail-vwlchq8e57.example.com'
Setting website configuration for Bucket: 'retail-vwlchq8e57.example.com'
Creating Role: api-vwlchq8e57-3q10ks11-iam-role-vwlchq8e57-3q10ks11
Setting redirection for Bucket: 'www.retail-vwlchq8e57.example.com'
Set policy and CORS for bucket 'retail-vwlchq8e57.example.com'
Creating API Gateway: "api-vwlchq8e57-3q10ks11"
Creating Site: 'retail-frontend'
Syncing files ...
REST API resources:
  POST - https://4ebcwp4pv2.execute-api.us-east-1.amazonaws.com/dev/products
  GET - https://4ebcwp4pv2.execute-api.us-east-1.amazonaws.com/dev/products/{id}
  GET - https://4ebcwp4pv2.execute-api.us-east-1.amazonaws.com/dev/catalog/{...categories}
Static Website resources:
  http://retail-vwlchq8e57.example.com.s3-website-us-east-1.amazonaws.com

The retail-app website can be accessed at the url: http://retail-vwlchq8e57.example.com.s3-website-us-east-1.amazonaws.com

Info

After deployment you can run this command to get access to the static website location and api endpoints:

$ components info

Remove

To remove the application and delete all dependent resources automatically, simply do:

$ components remove

The Application Structure

The retail-app application has the following structure:

• serverless.yml: the configuration file for the application
• index.js: the code file for the application
• code/: code folder for the aws-lambda child component
• data/products.json: seed data for products
• frontend/: code folder for the static-website child component.

Configuration

The serverless.yml is the config file that describes the application and its dependencies. This file is required.

The application is composed of the following attributes:

• type: a unique identifier that is used to reference the application
• components: a set of component dependencies that makes up the application. In turn, each component has the following attributes:
  • xxxxxx: a unique name for the instance of the component being used
  • type: a unique identifier that is used to reference the component
  • inputs: a pre-defined set of input parameters defined by the component. These inputs allow customisation of the component behavior.

Implementation

The index.js file contains any specifc code for the application, above and beyond what the child components provide. This file is optional.

The retail-app seeds the application's DynamoDB table, with some product data using the insertItem command exposed by its child component aws-dynamodb. The seed data is in the product.json file under the data folder.

Components

The retail-app application is composed of the following components:

• Web Frontend: It creates a S3-based static website with the content provided to it. It also uses a Mustache template to display data from the backend. It creates the necessary resources like S3 buckets, policies, CloudFront and Route53 mappings. It returns a url for the website. The static-website component encapsulates all that functionality.
• Lambda functions: It creates three Lambda functions with the handler code provided to it. It creates default roles and attaches it to the individual Lambda functions. The aws-lambda component encapsulates all that functionality.
• REST API: It creates a REST API for the AWS API Gateway. It takes a structure for the routes, and maps Lambda functions provided to it. The rest-api component encapsulates all that functionality.
• DynamoDB table: It creates a DynamoDB table with input parameters like name, keys, indexes, and a model schema. The aws-dynamodb component encapsulates all that functionality. See docs for details.
